Tiandy AK Series TC-R3104 Spec:I/B/P4/C/Eu/L/S/V2.0 4-Channel PoE NVR with 1-Bay HDD, HDMI & VGA Output & S+265 Compression

Description: The Tiandy AK Series TC-R3104 is a compact 4-channel PoE NVR designed for small surveillance deployments using Tiandy AK and Spark Series IP cameras. With 4 built-in PoE ports (28W total budget), 1-bay HDD storage up to 6TB, simultaneous HDMI and VGA outputs, S+265 compression saving up to 75% storage space, and cloud upgrade support — it is a cost-effective all-in-one recording solution for homes and small businesses.

Key Features:

• Access Channels: 4-ch IP camera; Incoming/Outgoing Bandwidth: 60Mbps / 40Mbps
• Max. Decoding: 6MP(30fps)x1 or 1080P(30fps)x4; 4-ch synchronous playback
• Resolution Support: 6MP/5MP/4MP/3MP/1080P/720P and below
• Video Compression: S+265, H.265, S+264, H.264 — S+265 saves up to 75% storage vs H.264
• HDMI Output: up to 1080P (1920x1080); VGA Output: up to 1080P — simultaneous display
• Multi-screen: 1/2/3/4 split on both HDMI and VGA simultaneously
• PoE Interface: 4x RJ45, 10/100 Mbps, IEEE 802.3af/at; PoE Budget: 28W total, up to 28W per port
• Network Interface: 1x RJ-45, 10/100 Mbps self-adaptive Ethernet port
• HDD: 1x SATA interface, up to 6TB per HDD
• Record Mode: Alarm Recording and Schedule Recording
• Alarm: Motion Detection, Mask Alarm, IPC Alarm Input, Video Loss, IP/MAC Conflict, Disk Full, PoE Overload, and more
• AI by Camera: Smart Motion Detection
• Third-party Camera: ONVIF, RTSP
• USB: 2x USB 2.0 for backup; Mobile: Android, iOS, P2P
• UI Language: English, Spanish, Italian, Turkish, French, Polish, Dutch, Hebrew, German, Portuguese
• Power Supply: DC48V 1A; Power Consumption: <10W (without HDD and PoE)
• Dimensions: 200 x 200 x 43mm; Net Weight: 0.44kg
• Operating temperature: -10 to +55 degrees C; Humidity: 10~90% RH
• Package includes: NVR, Screw Pack, Mouse, European Standard Power Adapter

Ideal For: Perfect for homes, retail shops, and small offices deploying up to 4 Tiandy PoE IP cameras — where a compact, all-in-one PoE NVR with built-in camera power, local HDD recording, HDMI display output, and S+265 storage-efficient compression is needed for a simple plug-and-play surveillance setup.
